| Model | SX5255ZYSDT434 |
| Series | F3000 |
| Driving form | 6X4 |
| Driving mode | LIFT HAND DRIVE |
| Appearance dimensions | Max. Length | 10,500mm |
| Max. Width | 2,600mm | |
| Max. Height | 3,450mm | |
| Wheelbase | （4375＋1400） mm | |
| Weight（kg） | Curb Weigh | 12,000Kg/ 12吨 |
| GVW/ PTAC | 40,000Kg/40吨 | |
| Loading weight/ | 25,000kg/25吨 | |
| Transmission | Model | 10JSD180＋QH50 |
| Forward/Reverse gear | 10Forward,2Revers | |
| Engine | Model | WP10.380E22（Euro2），WEICHAI |
| Rated output power Rated speed | 280kW 2200rpm | |
| Max. Torque | 1600N.m | |
| Displacement | 9.726L | |
| Frame | 850×300（8+5）mm | |
| Cab | Model | F3000 standard cabin, two seats,Manual windows lift,with A/C; |
| Suspension | Front Suspension | Multi-leaf spring suspension |
| Rear Suspension | Multi-leaf spring suspension ，Double U bolt | |
| Axle | Front axle | 7.5 Tons |
| Tyre | Type | 13R22.5( 10＋1pcs） |
| Fuel tanker | Capacity | 400 L |
| Cargo | dimensions | 20m³ |
| Material | Bottom 5mm ，side 4mm T420 | |
| weight | 6700Kg（approx） | |
| Compression ratio | ≥2.5 | |
| Effective volume of the filler | ≥2m³ |
| The time for one reload cycle | ≤30 s |
| Dump garbage time | ≤45s |
| Hydraulic system pressure | 20MPa |
| Control system | CAN + dedicated controller + silicone panel The specially set emergency brake button can make the garbage filling mechanism stop in any state or any position to ensure the safety of workers and equipment |
